Welded components Unicomp UNC225 NDT Industrial Inspection Doctor

  • 1
  • 2
  • 3

Brand Name : UNICOMP

Model Number : UNC225

Certification : CE

Place of Origin : China (Mainland)

MOQ : 1Set

Price : can negotiate

Payment Terms : T/T,L/C

Supply Ability : 300 sets per month

Delivery Time : 30 days

Packaging Details : Wooden Case, Waterproof, Anti-collision

Dimension : 2400mm*2400mm*2442mm(L*W*H)

Weight : 5T

Tube Type : Split Tube

Voltage : 225kv

Contact Now

UNICOMP Industrial X Ray Machine Real Time Imaging Inspection UNC225


UNC225 is a heavy-duty, high-stability industrial X-ray inspection solution, widely applicable to foundries, R&D centers, labs and academic institutions. Integrated with a premium digital flat-panel detector and high dynamic radioscopy technology, it captures sharp, high-resolution images with excellent clarity.


  • Smart ergonomics for easy operation
  • Tailor-made configuration for wheels and tires
  • Renowned, robust, reliable digital X-ray inspection system
  • Brilliant image quality with high contrast for spot-check samples and series inspection

Technical Data

Attribute Respective Value
Maximum penetration(FE) 150mm/25mm
Equipment weight 5T
System Dimension 2400mm*2400mm*2442mm(L*W*H)
X-ray Tube 225KV
Power 800W/1800W
Pixel Pitch 154μm
Mini Focal Spot 0.4mm/1.0mm
Max.Inspection Area Φ600mm x 800mm



Inspection Images:


Welded components Unicomp UNC225 NDT Industrial Inspection Doctor


UNC225 assists you in detection of casting flaws in items such as:


1. Aluminum castings (engine blocks, cylinders, cylinder heads, pistons, knuckles)

2. Turbine blades

3. Wheels and tires

4. Fiber-reinforced materials

5. Ceramics

6. 3D printed materials
