Unicomp AI algorithm X ray scan machine inspect 12mm thick sausage UNX4015

  • 1
  • 2

Model Number : UNX4015N

Heavy load Conveyor Speed : 10-40M/min

MOQ : 1 PCS

Delivery Time : 30 days

Conveyor Speed : 10-70M/min

Payment Terms : T/T,L/C

X-ray tube : 80kv,210W/350W

X-ray detector : Diode array with 0.4mm resolution

Price : USD

Power Supply : AC 220V, 50Hz

Max. Loading weight : 10kg

Supply Ability : 30 sets per month

Machine weight : 450kg

Brand Name : Unicomp

Certification : CE

Packaging Details : Unicomp package

Place of Origin : China

Contact Now

Unicomp AI Algorithm X-Ray Scan Machine UNX4015
High-precision X-ray inspection system designed to detect foreign contaminants in 12mm thick sausage products and other lightweight packaged goods.
Key Features
  • Detection Capability: High-precision automatic foreign-body detection for metals, ceramics, glass, bone, shell, and other contaminants
  • Adjustability & Alarms: User-adjustable sensitivity with integrated alarm management
  • Data Reporting: Comprehensive statistical reporting for quality traceability
  • Detection Performance: Industry-leading sensitivity powered by AI deep-learning intelligent algorithms
  • Maintenance Design: Tool-free removal for conveyor belt and protective curtains
Technical Specifications
Feature Specification
Dimension 1140(W) × 1160(D) × 1975(H) mm
Machine Weight 450 kg
X-ray Tube 80kV, 210/350W
Power Supply AC 220V, 50Hz
Max Loading Weight 10 kg
X-ray Detector Diode array with 0.4mm resolution
Channel Size 400mm(W) × 150mm(H)
Conveyor Speed 10-70 M/min
Heavy Load Conveyor Speed 10-40 M/min
Operating Range 10°C to 40°C (50°F to 104°F), 30% to 90% relative humidity non-condensing
Detection Accuracy SUS BALL ≥ ø0.3mm, SUS wire ≥ ø0.2×2mm, Glass ball ≥ ø1.0mm, Ceramic ball ≥ ø1.0mm
Communications 1×LAN, 2×USB
Industrial PC 15.6" HD touch screen; Windows 10
Ingress Protection Conveyor: IP66, Others: IP65
X-Ray Safety <1μSv/h
Optional Configuration
Rejector options include: Sound-Light alarm, flipper, dropout, air jet, pusher, chute, shuttle
Applications
UNX4015-N is used to detect foreign matter contaminants in small bags for lightweight products including candy, fresh meat, prawn, vegetable, poultry, chocolates, pasta, instant noodles, bread, biscuits, dried fish, ham sausage, beef jerky, nuts, and similar packaged goods.
Product Overview
Unicomp AI algorithm X ray scan machine inspect 12mm thick sausage UNX4015
Detection Image Example
Unicomp AI algorithm X ray scan machine inspect 12mm thick sausage UNX4015
